HFE – Half-flat Ceramic Infrared Heating Elements 400 W, 230 V | 122 x 60 mm | White

We also recommend the following product as an accessory

• Details
• Data
• Reviews

Details

Detailed Description:

Ceramicx ceramic infrared heating elements are suitable for a wide range of industrial and technical applications such as thermoforming, packaging, curing and drying of paint coatings. They can also be used in outdoor heaters, infrared saunas, or even for keeping food warm in display counters.
When used with a type K thermocouple, the desired temperature can be set. However, a temperature controller is also required for this.

Technical Specifications:

• Power: 400 W
• Dimensions: 122 x 60 x 26 mm
• Resistance wire: Iron-Chrome-Aluminium
• Voltage: 230 Volt
• Effective wavelength range: 2–10 microns
• Average operating life: 20,000 hours (depending on conditions)
• Recommended radiation distance from the heating unit: 100 mm – 200 mm

Data

Sizes:

122 x 60 mm

Voltage:

230 V

Wattage:

400 W

Weight:

105 g/db
